100% PET woven dryer fabric

100% PET woven dryer fabric

100% PET woven dryer fabric

Product Details:

Place of Origin: Anhui,China
Brand Name: Sinostar
Certification: ISO9001:2000,SGS.
Model Number: polyester dryer fabric

Payment & Shipping Terms:

Minimum Order Quantity: 100 square meters
Price: 20 usd / square meter
Packaging Details: PP bags and Wooden box, Standard export package.
Delivery Time: 20 days according to your QTY
Payment Terms: T/T or L/C
Supply Ability: 3000 square meters per month
Contact Now
Detailed Product Description

Dryer fabrics parameter

Modle

of fabric

Wire

Diameter
(mm)

Density
(thread/cm)

Air

permeability
m3/m2h

Strength(N/cm)

Max.

Elongation
at 50N/cm

Thickness
(mm)
Warp Weft Warp Weft Surface Jointing
24503 0.5 0.5 24-25 11-12 6000 >2500 >1000 <0.5% 1.6
24504 0.5 0.5 25-26 11-12 11000 >2500 >1000 <0.5% 2
24504-A 0.5 0.5 24.5-25.5 11-12 7500 >2500 >1000 <0.5% 1.7
4106-C-1 0.36*0.62 0.35/0.68 19-20 12-13 4000 >1800 >1000 <0.5% 1.5
4106-C-2 0.36*0.62 0.35/0.68 19-20 14-15 3000 >1800 >1000 <0.5% 1.5
4106-D-1 0.36*0.62 0.5 19-20 12-13 5000 >1800 >1000 <0.4% 1.4
4106-D-2 0.36*0.62 0.5 19-20 15-16 3000 >1800 >1000 <0.4% 1.4
4106-K-1 0.32*0.8 0.4/0.68 19-20 12-23 4500 >1900 >1000 <0.35% 1.45
4106-K-2 0.32*0.8 0.4/0.68 19-20 14-15 3000 >1900 >1000 <0.35% 1.45



Dryer fabric:

it is a drying part of wet Paper web. The conventional Drying system can dry the wet web from 60% moisture to 2% moisture

with help of DRYING FABRICS. DRYING FABRICS play an important roll for giving a final shape and parameters to the PAPER.

DRYING FABRICS are also known as Conveyor Belts. The sheet is mechanically pressed against the drying Cylinders.

These days these DRYING FABRICS are also in use of Silent Drive System in Dryers. The selection of these DRYER

SCREEN is depending on the paper grades,Dryers configuration, Dryers temperatures and many more parameters.

Our DRYER FABRICS have an average running life of three to Twelve months (Even More than this which is depending on

the usage and many more machine parameters.)
