paper making industry polyester 2-shed plain weave pulp washing fabric

paper making industry polyester 2-shed plain weave pulp washing fabric

    • paper making industry polyester 2-shed plain weave pulp washing fabric
    • paper making industry polyester 2-shed plain weave pulp washing fabric
    • paper making industry polyester 2-shed plain weave pulp washing fabric
  • paper making industry polyester 2-shed plain weave pulp washing fabric

    Product Details:

    Place of Origin: Anhui, China.
    Brand Name: Sinostar
    Certification: ISO9001:2000,SGS.
    Model Number: pulp washing mesh

    Payment & Shipping Terms:

    Minimum Order Quantity: 100 square meters
    Price: USD 15-22 square meter
    Packaging Details: Plastic bag inside and wooden crate outside
    Delivery Time: 15-25 work days
    Payment Terms: T/T or L/C, Western Union
    Supply Ability: 5000 square meters per month
    Contact Now
    Detailed Product Description
    Material: 100% Polyester Pattern: Plain Weave
    Structure: 2-shed Feature: Heat-Insulation, Shrink-Resistant, Tear-Resistant
    Application: Paper Making Pulp Washing

    Paper making industry polyester 2-shed plain weave pulp washing fabric

    paper making industry polyester 2-shed plain weave pulp washing fabric

    paper making industry polyester 2-shed plain weave pulp washing fabric

    paper making industry polyester 2-shed plain weave pulp washing fabric

    Specifications



    Material: 100% polyester Type: plain

    Pattern: crepe Techniques: woven

    Yarn count: 0.8mm Weight:0.35-0.77kg/ m²



    Features

    • Acid resistance
    • Alkali resistance
    • Oil resistance
    • Hydrolytic resistance
    • Long life service

    Technical Index

    Weaving

    Type

    Model Thread Diameter(mm) Density(No.s/cm)

    Strength

    (N/cm)

    Air Permeability

    (m³/m²h)

    Warp Weft Warp Weft
    2-shed plain weaving fabric 05082 0.7 0.8 4.7-5.0 4.8-5.0 940 >20000
    05102 1.0 1.0 4.7-5.2 4.3-5.0 1600 >15000
    06702 0.7 0.7 8.0 7.0 1600 11000
    07102 0.7 1.0 6.6-7.0 4.3-4.6 1100 >15000
    08552 0.55 0.55 7.5-8.0 8.5-9.0 850 850-6500
    09452 0.45 0.45 10.0 8.6 1600 1600
    09502 0.5 0.5 8.5-9.0 10-10.5 750 >10000
    12502 0.5 0.5 13.5 8.5 1800 6500
    3-shed plain weaving fabric 08603 0.5 0.6 10.0 9.0 1600 14000
    08903 0.9 0.9 7.8-8.0 5.0-5.5 2100 7500-8500
    07803 0.7 0.8 8.0 8.0 1600 10000
    20353 0.3 0.34 22.0 14.5 1200 13000
    20403 0.3 0.4 22.0 14.5 1200

    13500



    Applications

    Polyester Pulping Fabrics is used in several of washing equipments. It’s most used in the horizontal belt washer,vacuum washer and rotary drum vacuum washer. The 2-shed plain woven fabric is mainly used in special lines, such as paper pulps making, Sulplate pulp packing and pulp, fiberboard plabts as well as colliery, food and medicine as conveyor belt.

    Plain weaving fabrics are mainly used in the production of pulp board papermaking,fourdrinier paper machine,artificial board auxiliary mesh belt.screening,drying,environmental protection and other industries.



    Sinostar specialized in paper and pulp industry for many years, we mainly supply all kinds of spare parts as following:

    • Paper machine clothing: forming fabrics, dryer screens, pulp washing fabrics, paper making felts,sludge dewatering belts, stainless steel wire mesh,etc.
    • Pulping equipments: screen baskets, screen plates, refiner plates,etc.
    • Pulp cleaner: high density cleaner, low density cleaner,Medium density cleaner, ceramic cone,etc.
    • Spray nozzle: flat fan nozzles,full cone nozzle, hollow cone nozzles, needle jet nozzles,low pressure misting nozzles, etc.
    • Blades and knives: doctor blades, paper cutting knives, slitter knives,steel rule blades, carton box slotting knife,packaging machine blades,etc.
    • Other paper machine spare parts: pulp rotors,pressure screens,suction cover box,plain bearings,etc.

    If you are interested in any our products, please contact us for more details.
