Place of Origin: | Maanshan,China. |
Brand Name: | Sinostar |
Certification: | ISO9001:2000 |
Model Number: | paper cutting knife |
Minimum Order Quantity: | 1 piece |
---|---|
Price: | $ 45-280 /piece |
Packaging Details: | Export standard packing with wooden case |
Delivery Time: | 25-30 days |
Payment Terms: | T/T, L/C, or Paypal |
Supply Ability: | 1000 pcs per month |
Material: | HSS, SKD11, Tungsten Carbide, Etc. | Dimension: | 610mm X 68.4mm X 4.76mm |
---|---|---|---|
Parallelism Tolerances: | Within 0.003mm | Hardness: | HRC40~68 Degree |
Merits: | High Precession,Good Wear-resistance | Application: | Tissue Paper / Toilet-Roll Paper Cutting |
Parameter sheet
Material | D2 / SS / H13 / HSS / SLD / SKH / Alloy Steel / Tungsten carbide etc. |
Finish(coating) | Precision finish, Mirror finish, Lapping finish available. |
Design | Solid carbide,single edge carbide tipped,double edge carbide tipped. |
Shape | Circular/Round |
Dimension | Custom |
OD tolerance | ± 0.01 mm. |
ID tolerance | ± 0.03 mm. |
Sample | Available. |
OEM & ODM | Capability. |
Main market | USA,France,Pakistan,Thailand,Vietnam,Bangladesh,Russia,etc. |
Specification (customized shape and dimension is acceptable)
Diameter | Bore | Thickness(mm) |
610 | 68.26 | 4.76 |
610 | 68.26 | 3.80 |
610 | 82.55 | 4.76 |
610 | 82.55 | 3.80 |
610 | 100.0 | 4.76 |
610 | 100.0 |
3.80 |
According to your application ,we will recommend you the best material and hardness.
Optional Materials :9CrSi , 6CrW2Si , LD , D2 , Cr12MoV , H13 , G1, G2 ,G3 and etc .We developed some high alloy steel ,like G1,G2,G3 etc. They are new materials developed independently by our company and excellent in high intensity, high hardness , high wear resistance , high toughness and so on.They can be used in both cold and hot shearing ,the life is 2-3 times longer than other blades made of normal materials.
Hardness : If hardness is high , when the blades meet higher tensile strength steel ,it is easy to crack.
If the hardness is low , then the wear resistance is not good ,that means work life is shorter .
Features and Benefits
Main Applications
Packing way
A. Inside packing: Applied with anti-rust oil and then packed in plastic bag.
B. Outside packing: Packed in plywood case.
Key Performance Indicator
Standard Revolution of Knives
Before using knives
Our Commitments
Sinostar supply all kinds of paper and pulp machinery spare parts, our main products as following:
If you are interested in any our products, please contact us for more details.
