Place of Origin: | Anhui, China. |
Brand Name: | Sinostar |
Certification: | ISO9001:2000,SGS,CE. |
Model Number: | sludge dewatering belt |
Minimum Order Quantity: | 50 square meters |
---|---|
Price: | USD 15-24 square meter |
Packaging Details: | Plastic film inside and wooden case outside |
Delivery Time: | 15-20 work days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 8000 square meters per month |
Material: | 100% PET, Polyester. | Seam Type: | Steel Clip |
---|---|---|---|
Thickness: | 2.0mm | Air Permeability: | High |
Strength: | High | Application: | Paper Industry, Wastewater Treatment, Filter Press |
Features
Using
Sludge dewatering fabric is mainly used for sludge de hydration in sewage treatment factories.They have the characteristics of good water permeability, air permeability and non-revealed sludge, acid-resisting, alkali-resisting, heat resistance (180°C) .Because of their designing structure, the sludge
can be peeled off easily after pigeonhole filter, so the screen are easily cleaned and have a long working time.Therefore they are designed specially for sludge dehydration.
Model
|
Wire diameter
mm |
Density
Root/10cm |
Air permeability
m3/m2h |
Net weight
g/m² |
Strength
N/cm |
Used in
|
||
Warp
|
Weft
|
Warp
|
Weft
|
|||||
WNW14803
|
0.7
|
0.8
|
142
|
47-60
|
3900-
11052 |
1400
|
2400
|
Sludge,
Squeeze juice |
WNW16803
|
0.7
|
0.8
|
156
|
46-50
|
6500-8200
|
1400
|
2650
|
Sludge, Squeeze juice
|
WNW16904
|
0.75
|
0.9
|
156
|
47
|
14500
|
1800
|
2800
|
Iron and steel industry sludge dewatering
Living sludge dewatering |
WNW121054
|
0.9
|
1.05
|
120
|
42
|
11500
|
1650
|
3400
|
Iron and steel industry sludge dewatering
|
WNW22903
|
0.5
|
0.9
|
220
|
50-55
|
12100
|
1200
|
2000
|
Living sludge dewatering
|
WNW20703
|
0.5
|
0.7
|
200
|
70
|
10000
|
1000
|
1850
|
Living sludge dewatering
Chemical sludge dewatering |
GW24504
|
0.5
|
0.5
|
240
|
130-140
|
9900
|
1180
|
2200
|
Paper dry network
Paper sludge dewatering |
WNW08903
|
0.9
|
0.9
|
78
|
50
|
10000
|
1430
|
2100
|
Industrial sludge dewatering
|
WNW16704
|
0.7
|
0.7
|
160
|
90
|
12000
|
1350
|
2650
|
Building materials industries
|
WNW26908
|
0.5
|
0.9
|
26.4
|
69-75
|
5000-5500
|
1364
|
2400
|
Viscosity of the larger
Sludge |
Reasons to choose Sinostar?
1. High strength & density.
2. Acid-resisting & alkali-resisting.
3. Heat resistant.
4. Longer service life.
5. User-customized products.
FAQ
Q: What kind of filter fabric do you offer?
We maily offer filter the belt/mesh which is used for dewatering and filtration in papermaking process.
Q: What kind of equipment are your products used in?
Our products are mainly used in pulp washing,forming section,dryer section, press section in papermaking process.
Q: Do you have any MOQ limit?
A: Our MOQ limit is 50 m2, accept sample testing.
Q:What colors of filter belts do you provide?
We provide any colors you want.
Q: How can I know which kind of filter belt is best for me?
We will make an expert recommendation to you.
